技术参数
输出功率8ΩStereo Power | 450W×2 |
4ΩStereo Power | 675W×2 |
2ΩStereo Power | 900W×2 |
桥接功率8ΩBridge Power | 1100W |
4ΩBridge Power | 1130W |
频响Frequency Response | 20Hz-20KHz +0/-0.5dB |
失真度THD+N | ＜0.02%@8Ω 1KHz |
信噪比S/N Rate | ＞100dB(A Weighted A计权) |
转换速率Slew Rate | 35V/μS |
阻尼系数Damping Factor | ＞300@8Ω |
通道隔离度Crosstalk | ＞60dB@8Ω 1 KHz |
输入阻抗Input Impedance | 20KΩ(Balance平衡)/10KΩ(Unbalance非平衡) |
输入灵敏度Input Sensitivity | 0.775V/1V/1.4V |
保护功能Protect | DC直流保护, Short Circuit短路保护, |
Over Heat过热保护, Soft-Start开机软启动 | |
面板功能Front Panel CNT | Power Switch,CHA CHB Volume电源开关和音量控制 |
后板功能RearPanel CNT | Mode,Sensitivity工作模式和灵敏度控制 |
尺寸Size | 2U(48.2cm/L x 46.5cm/D x 8.8cm/H) |
包装Packing Dimensions | 570mm×550mm×145mm |
毛重Gross Weight | 21.00Kg |
